WEICON Professional Crimp Set

WEICON Professional Crimp Set is a professional hand tool set developed for the preparation and termination of electrical connections, combining stripping and crimping steps in a single package. The set includes the Duo-Crimp No. 300, the Wire Stripper No. 7 Magic, and a total of 400 wire end ferrules in the 0.5-2.5 mm² range compliant with DIN 46228. This configuration enables controlled work with different conductor types, especially in panel assembly, field wiring, and maintenance applications. Since the product offers a mechanical and process-oriented connection solution rather than a chemical consumable, its performance is evaluated in terms of cross-section compatibility, accessibility, ergonomics, and repeatable application quality.

Technical structure and set contents of the Crimp Set Pro
The main crimping component of the set, the Duo-Crimp No. 300, is a multifunctional solution that combines stripping and crimping functions in a single body. This tool has an insulation stripping range of 0.5-6.0 mm² and provides two separate crimping ranges: 0.5-2.5 mm² and 4.0-6.0 mm²; it also includes an integrated side cutter up to 6 mm². Since the ferrules included in the set are supplied according to DIN 46228, orderly and standardized termination is targeted especially in control panels and terminal connections. According to the manufacturer, the product is marketed by WEICON GmbH & Co. KG, based in Germany, and also has an established presence in Turkey. In this respect, the set offers a more organized and field-ready solution compared to the use of scattered individual tools.

Usage performance and application flow
The second main component of the professional set, the Wire Stripper No. 7 Magic, is an ergonomic cable stripper with a fiberglass-reinforced polyamide body and an automatic scanning system. Its operating range of 0.5-16 mm² for flexible conductors and 0.5-10 mm² for solid round conductors helps provide broader coverage across different installation and assembly scenarios with a single tool. The 8-24 mm visual length scale and 5-stage fine adjustment reduce the risk of damaging the inner conductor and allow for more repeatable preparation. The typical application process involves stripping the conductor to the appropriate length, selecting the correct ferrule size, and then crimping it in the proper slot with the Duo-Crimp. The manufacturer also clearly states that these tools must not be used on live cables or conductors.

Industrial applications and compatible systems
This set offers practical use in electrical panel manufacturing, building electrical installations, maintenance and repair, HVAC electrical connections, automation wiring, service teams, and general industrial assembly processes. It forms a suitable combination for preparing ferruled connections, especially in applications involving stranded and solid conductors. It is compatible with systems that require neat wire-end termination, such as terminals, terminal blocks, control cabinets, and internal device wiring. In the manufacturer’s catalogs, the product family is associated with various areas of use such as electrical work, customer service, automotive, refrigeration and air conditioning, radio and television, and household technical applications. For this reason, the set is suitable not only for a single assembly task but also for multiple usage scenarios that vary between field and workshop environments.

Certification, advantages, and evaluation
The product’s key advantages include being supplied as a complete set, offering flexibility across different cross-sections, reducing processing steps thanks to integrated side cutters, and providing ergonomic handling. Safety test information from TÜV NORD is available for the Wire Stripper No. 7 Magic, while TÜV GS certificate download links are also provided for the relevant tool family on the set page. Since values such as heat resistance, chemical resistance, or pressure resistance are not the main focus in this product group, performance evaluation is based more on mechanical function, cross-section range, and safe application capability. As a result, the WEICON Professional Crimp Set is a technically balanced and practically relevant solution for professionals seeking order, speed, and process continuity in ferruled electrical connections.
